Specifications

• Cooling Capacity: 34,400 Btu/h
• Min Cooling Capacity: 10,200 Btu/h
• Max Cooling Capacity: 34,400 Btu/h
• Heating Capacity: 36,000 Btu/h
• Min Heating Capacity: 10,200 Btu/h
• Max Heating Capacity: 36,000 Btu/h
• Heat Insulation: Both Liquid and Gas Pipes
• Amount of Additional Charge of Refrigerant: 0.32 oz/ft
• Airflow Rate (H) - Cooling: 915 ft³/min
• Airflow Rate (H) - Heating: 960 ft³/min
• Airflow Rate (M) - Cooling: 742 ft³/min
• Airflow Rate (M) - Heating: 791 ft³/min
• Airflow Rate (L) - Cooling: 572 ft³/min
• Airflow Rate (L) - Heating: 629 ft³/min
• Airflow Rate (SL) - Cooling: 512 ft³/min
• Airflow Rate (SL) - Heating: 544 ft³/min
• Fan Type: Cross Flow Fan
• Fan Speed: 5 Steps, Quiet, Auto
• Running Current (Rated) - Cooling: 0.77 to 0.82 A
• Running Current (Rated) - Heating: 0.75 to 0.82 A
• Power Consumption Rated - Cooling: 95.0 W
• Power Consumption Rated - Heating: 95.0 W
• Power Factor - Cooling: 55.1 to 55.7 %
• Power Factor - Heating: 55.1 to 55.7 %
• Temperature Control: Microcomputer Control
• Sound Pressure Level (H) - Cooling: 54 dBA
• Sound Pressure Level (H) - Heating: 53 dBA
• Sound Pressure Level (M) - Cooling: 47 dBA
• Sound Pressure Level (M) - Heating: 46 dBA
• Sound Pressure Level (L) - Cooling: 40 dBA
• Sound Pressure Level (L) - Heating: 38 dBA
• Sound Pressure Level (SL) - Cooling: 37 dBA
• Sound Pressure Level (SL) - Heating: 35 dBA
• Front Panel Color: White
• Gross Weight: 49 lb
• Weight: 38 lb

System EfficiencyMetrics

• System Performance SEER:15.90
• System Performance EER: 9.6 Btu/h·W
• System Performance HSPF: 9.20
• System Performance COP: 2.80

Dimensions

• Height: 13-3/8 in
• Width: 47-1/4 in
• Depth: 10-3/16 in
• Packaged Depth: 16-7/8 in
• Packaged Width: 51-9/16 in
• Packaged Height: 13-7/16 in
• Pipe Connections - Liquid: 1/4 in
• Pipe Connections - Gas: 5/8 in
• Pipe Connections - Drain: 5/8 in
• Max. Interunit Piping Length: 98-3/8 ft
• Max. Interunit Height Difference: 65-5/8 ft
